Large-size flip-chip COB video wall built for 24/7 monitoring, control rooms and data centers.
Recommended: 10% extra spare parts (modules, receiving cards, power supplies), approx. from $29 (≈5% of the order, updates with your selection).
Shipping and transportation are quoted separately.
Price range: $570.00 through $1,200.00
The firefly series LED display is a large size full flip chip cob display for monitoring application market.
Flexible splicing of large and small size cabinet, maximize meet the installation size requirement.
Dual receiving card and power supply options provide four times safety, video wall never black out.
Special treatment with G0B technology, enabling surface water-resistant, dust-resistant,
impact-resistant and anti-static.
Large-sized cabinet, offering quick installation and seamless splicing for large-area display, saving time and effort.
Tap a model to select it — the highlighted column is your current selection.
| Model | 63V09 | 63V12 | 63V15 | 63V18 |
|---|---|---|---|---|
| Pixel Configuration | Flip Chip COB | Flip Chip COB | Flip Chip COB | Flip Chip COB |
| Pixel Pitch(mm) | 0.93 | 1.25 | 1.56 | 1.87 |
| Cabinet Size(mm)(WxHxD) | 600x337.5x40/1,200x675x40 | 600x337.5x40/1,200x675x40 | 600x337.5x40/1,200x675x40 | 600x337.5x40/1,200x675x40 |
| Cabinet Resolution(WxH) | 640X360/1,280X720 | 480X270/960X540 | 384X216/768X432 | 320X180/640X360 |
| Cabinet Weight(kg/cabinet) | 4.4/16.5 | 4.4/16.5 | 4.4/16.5 | 4.4/16.5 |
| Refresh Rate(Hz) | 3,840 | 3,840 | 3,840 | 3,840 |
| Grayscale(bit) | 14-16 | 14-16 | 14-16 | 14-16 |
| Brightness(nits) | 600 | 600 | 600 | 600 |
| Viewing Angle (H/V) | 170°/170° | 170°/170° | 170°/170° | 170°/170° |
| Working Voltage | AC 100V~240V,50~60Hz | AC 100V~240V,50~60Hz | AC 100V~240V,50~60Hz | AC 100V~240V,50~60Hz |
| Lifetime(H) | 100,000 | 100,000 | 100,000 | 100,000 |
A fine-pitch indoor LED wall for churches, boardrooms, lobbies, control rooms and studios, where people sit close and image quality matters. Not sure which size or pitch you need? Try the LED wall selector.
Unity Logics supplies, installs and supports this equipment across Southern California. Request a quote or book a free site survey.
Tell us about your project and our team will get back to you with pricing, availability and the right configuration — usually within one business day.
Tell us your venue size, audience count, and event type. Unity Logics can recommend the right package.
Unity Firefly Series-COB
SKU: UL-LED-FIREFLY-COB
Variant
Start Your Inquiry
Select your project type so we can ask the right questions.
Panels, NovaStar processor, cabling and frame in one price. Installation and shipping quoted separately.
7.9′ × 4.4′ (108″) P1.25 Indoor – Firefly COB7.9′ × 4.4′ · P1.25$18,650
9.8′ × 5.5′ (136″) P1.25 Indoor – Firefly COB9.8′ × 5.5′ · P1.25$29,150
11.8′ × 6.6′ (163″) P1.25 Indoor – Firefly COB11.8′ × 6.6′ · P1.25$41,950
13.8′ × 7.8′ (190″) P1.25 Indoor – Firefly COB13.8′ × 7.8′ · P1.25$57,100
15.7′ × 8.9′ (217″) P1.25 Indoor – Firefly COB15.7′ × 8.9′ · P1.25$74,600All 15 Firefly COB packagesOther pitches and sizes, filter by budget→Most LED walls look alike on a spec sheet. The difference is in the parts you can’t see. We choose each one for the job, and we tell you exactly what they are.
Panel and package prices are published on the site. Spare parts, shipping and installation are shown as separate lines, so you see exactly what you pay for.
We only sell screens we would put our own name on. Every series is chosen and checked against our spec before it joins the catalog.
Serviceable modules, spare parts ordered with your wall and components picked for long service life, so it still looks right years from now.
You get the parts list for your screen. Ask why we chose any component and we will walk you through it.
